Specification
Circumferential magnetizing current AC: 0~2000A
Longitudinal magnetization potential: AC: 0~12000AT
Electrode spacing: 100~600mm adjuctable (manual)
Magnetization sensitivity: 15/50 clearly displayed on A sensitivity test piece
Duty cycle ≥25%, continuous magnetization time maximium 3s
Magnetization method: circumferential magnetization, longitudinal magnetization, compound magentization
Clamping method: pneumatic clamping
Running mode: pneumatic/manual
Electrode plate: Ø160mm
Magnetizing coil: coil inner diameter Ø200mm two, coil turns 6 turns
Demagnetization: automatic attenuating demagnetization, residual magnetism ≤0.3mT
UV (Light) Lux: ≥2000uW/cm² (calibration at the distance of 381mm)
Power supply: 380V three-phase alternating current, 50Hz
Air supply: 0.4~0.7MPa
Operation environment: temperature: -5~45°C, relativehumidity: ≤90%
Dimension (LxWxH): main unit: 2600x850x1700mm, including darkroom dimension: 2800x1600x2200mm
Weight: 700kg
Standard Delivery
Electrical control system: 1pc
Magnetized power system: 2pc
Spray system: 1pc
Magnetic suspension recovery device: 1pc
Ultraviolet flaw detection lamp: 1pc
Demagnetization system: 1pc
