Detection channel: 2
Depth measurement range: 5~500mm
Width measurement range: 0.01~10mm
Sound time measurement range: 0~4096000μs
Wave amplitude measurement range: 0~170dB
Sampling interval: 0.025μs-2000μs multi-speed selectable
Sampling length: 512 points~2048 points multi-speed selectable
Transmit pulse width: ≤10μV
Emission voltage: 0.1μs~100μs
Trigger method: 125V, 250V, 500V, 1000V selectable
Storage: automatic, built-in 16GB
Data output: USB, WIFI
Operating temperature: -20~60°C
Power supply: rechargeable lithium battery, working time >8 hours
Dimensions (L×W×H): 283×216×41mm
Weight: 1.8kg
