Basic
Sensor: IMX678
Image Sensor: 1/1.8"CMOS
Shutter: Rolling
Resolution: 3840 × 2160
Frame Rate: 14.5 fps
Bit Depth: 12
Mono/Color: Color
Pixel Size: 2.0 μm × 2.0 μm
Pixel: 8 MP
S/N Ratio: 39.7 dB
Dynamic Range: 66.5 dB
Image Format: Mono8,BayerRG8/10/10Packed/12/12Packed,YUV422_8_UYVY,YUV422_8
Binning: Support
ROI: Support
Gain: 0～72 dB
White Balance: Support
Gamma: From 0 to 4, support LUT
Exposure Time: 16 μs～1 s
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
SPC: Support
Performance
User Setting: Support three sets of user-defined configurations
Image Buffer: 256MB
Port
Port: GigE, PoE
GPIO Interface: 1× 6 pin Hirose: 1× Opto-isolated input, 1× Opto-isolated output, 1 configurable input and output
Lens Mount: C-mount
Power
Power Supply: PoE/ DC 9V~24V power supply via Hirose interface
Power Consumption: 12 V≈3.8 W
Structure
Product Dimensions: 29 mm × 29 mm × 42 mm (not including lens mount and rear case connector)
Net Weight: 94 g
Environment
Storage Temperature: -30℃～+80℃
Operating Temperature: 0℃～+50℃
