Rated (0~40°C):
- Voltage: 0~1200V
- Current: 1.5A/7.5A/75A
- Power: 1.8KW/6kW
CV mode:
- Range: 0~120V, 0~1200V
- Resolution: 10mV; 100mV
- Accuracy: ±(0.05%+0.05%FS); ±(0.05%+0.05%FS)
CC mode:
- Range: 1.5A, 7.5A, 75A
- Resolution: 40uA; 0.2mA; 2mA
- Accuracy: ±(0.05%+0.1%FS); ±(0.05%+0.05%FS); ±(0.05%+0.05%FS)
CR mode:
- Range: 0.2Ω~10Ω / 10Ω-7.5KΩ
- Resolution: 16 bit
- Accuracy: 0.01%+0.08%S; 0.01%+0.0008%S
CP mode:
- Range: 6KW
- Resolution: 0.1W
- Accuracy: 0.2%+0.2%FS
Dynamic mode (CC mode):
- T1&T2: 20µs~3600S/Res: 1µs/10ms/100ms
- Accuracy: 5µs±100ppm
- Rise/fall slope: 0.00004 ~0.05A/µs; 0.0002~0.3A/us; 0.002~5 A/uS
Readback voltage:
- Range: 0~120V, 0~1200V
- Resolution: 10mV / 100mV
- Accuracy: ±(0.025%+0.025%FS); ±(0.025%+0.025%FS)
Readback current:
- Range: 1.5A, 7.5A, 75A
- Resolution: 40uA / 0.2mA/ 2mA
- Accuracy: ±(0.05%+0.1%FS) / ±(0.05%+0.05%FS) / ±(0.05%+0.05%FS)
Readback power:
- Range: 6KW
- Resolution: 0.1W
- Accuracy: ±(0.2%+0.2%FS)
Weight: 40 kg
