Direct access to our certified experts
Rated (0~40℃)
Input voltage: 0~120 V
Input current: 0~240 A
Input power: 3000 W
Min operating voltage: 0.12Vat24A, 1.2Vat 240A
CV mode
Range: 0.1~18 V/ 0.1~120 V
Resolution: 1 mV/ 10 mV
Accuracy: ±(0.025%+0.05% FS)
CC mode
Range: 0~24 A/ 0~240 A
Resolution: 1 mA/ 10 mA
Accuracy: ± ( 0.05% + 0.05%FS )
CR mode
Range: 0.01 Ω~10 Ω/ 10 Ω~7.5 KΩ
Resolution: 16 bit
Accuracy: 0.01% + 0.08S/ 0.01% + 0.0008S
CP mode
Range: 3000 W
Resolution: 100 mW
Accuracy: 0.2% + 0.2% FS
Measuring range
Readback Voltage:
Range: 0~18 V/ 0~120 V
Resolution: 1 mV/ 10 mV
Accuracy: ± ( 0.025% + 0.025%FS)
Readback Current:
Range: 0~24 A/ 0~240 A
Resolution: 1 mA/ 10 mA
Accuracy: ± ( 0.05% + 0.05%FS )
Readback Power:
Range: 3000 W
Resolution: 100 mW
Accuracy: ± ( 0.2% + 0.2%FS )
Input terminal impedance: 300kΩ
Size(W*H*D): 439 mm* 133.3 mm* 580 mm
