Width: 4.9 mm
Height: 16.07 mm
Length: 10.36 mm
Features: Planar passivated chip
Application: DC motor control
Unit Weight: 2.300 g
REACH - SVHC: Details
Current Rating: 16 A
Mounting Style: Through Hole
Vf - Forward Voltage: 1.27 V
Holding Current Ih Max: 60 mA
Breakover Current IBO Max: 340 A
Gate Trigger Current - Igt: 30 mA
Gate Trigger Voltage - Vgt: 1.3 V
Operating Temperature Range: - 55 C to + 150 C
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
On-State RMS Current - It RMS: 25 A
Maximum Gate Peak Inverse Voltage: 10 V
Off-State Leakage Current @ VDRM IDRM: 2 mA
Rated Repetitive Off-State Voltage VDRM: 800 V
