Width: 5.21 mm
Height: 21.34 mm
Length: 16.13 mm
Features: Planar passivated chip
Application: DC motor control
Unit Weight: 5.300 g
REACH - SVHC: Details
Current Rating: 45 A
Mounting Style: Through Hole
Vf - Forward Voltage: 1.37 V
Holding Current Ih Max: 100 mA
Breakover Current IBO Max: 560 A
Gate Trigger Current - Igt: 80 mA
Gate Trigger Voltage - Vgt: 1.5 V
Operating Temperature Range: - 40 C to + 150 C
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 40 C
On-State RMS Current - It RMS: 71 A
Maximum Gate Peak Inverse Voltage: 10 V
Off-State Leakage Current @ VDRM IDRM: 3 mA
Rated Repetitive Off-State Voltage VDRM: 1.6 kV
