Direct access to our certified experts
Function: Single wire, Multicore cable, Wire measuring, Cut length, Full stripping, Partial stripping, Mid-stripping, Cut depth, Wire lack sensor, Length correction
Raw material: PVC, Teflon, Silicone, Low halogen, Fiberglass, etc
Cutting length (L): 0.1-999999 mm
Conductor cross-sections: 0.1-25 mm², 12 mm diameter
Middle strip: 13 sections
Stripping length: Front (right) side: 250 mm [partial stripping], Rear (left) side: 120 mm [partial stripping]
Production rate: 1000 pcs/h by 100 mm wire length
Display: 7" color touchscreen, English / Chinese [other languages on request]
Compatible peripherals: Cable prefeeding machine, robot arm, conveyor belt
Power supply: AC 110V-220V ± 10%, 50/60 Hz
Air supply: 0.4-0.7 MPa (clean and dry air)
Dimensions: L 650 x W 580 x H 450 mm
Weight: 70 KG
