Function: Multicore cable, Single wire, Wire measuring, Cut into length, Full stripping, Partial stripping, Wire lack sensor, Length correction
Raw material: PVC, Teflon, Silicone, Low halogen, Fiber glass, etc
Cable diameter: 14 mm
Conductor cross-sections: 0.1 - 16 mm² [AWG 28 - 6]
Cutting length (L): 0.1 - 999999 mm
Cutting length accuracy: 0.002 x L
Stripping length:
Leading (right) side: 400 mm [partial stripping]
Trailing (left) side: 180 mm [partial stripping]
Production rate: 1200 pcs/h
Data library: 100 programs
Feeding unit: Servo motorized belt system
Display: 7" color touchscreen, English / Chinese [other languages on request]
Compatible peripherals: Cable prefeeder, robot arm, cable stacker
Power supply: AC 110 - 220 V ± 10%, 50 / 60 Hz
Air supply: 0.4 - 0.7 MPa (clean and dry air)
Dimensions:
Machine: L 700 x W 560 x H 1050 mm
Wire straightener: 350 mm
Weight: 110 KG
• Servo motorized belt feeding unit
• Upper and lower rollers open & close simultaneously
• Uniform center points of rollers, guides, and cutter blades
• Roller distance and pressure all programmable via touchscreen
• Wire run-out sensor gives machine stop signal
• 7" color touchscreen simplify programming
• Automatically calibrate the cutting length
• Heavy-duty cable up to 14 mm O.D
