Function: Single wire, Multicore cable, Wire measuring, Cut into length, Full stripping, Partial stripping, Cut depth, Cut speed, Feed speed, Run-out sensor, Length correction, Safety door sensor
Raw material: PVC, Teflon, Silicone, Low halogen, Fiberglass, etc
Conductor cross-sections: 10 - 120 mm²
Cable diameter: 4 - 24 mm
Guide tube: 8 sets
Cutting length (L): 1 - 99999.9 mm
Cutting length accuracy: 0.002 x L
Stripping length:
Front (right) side: 1 - 200 mm
Rear (left) side: 1 - 200 mm
Feeding system: 20 rollers, belt-driven
Blade material: High-speed steel
Blade type: V-blade, radius blade
Production rate: 700-1000 pcs/h [depends on cutting length]
Data library: 100 programs
OEM: Yes
Display: 7" color touchscreen, English / Chinese [other languages on request]
Compatible peripherals: Printer, coiler, wire prefeeder, robot arm, conveyor belt
Rated power: 1800 W
Power supply: AC 110-220 V ± 10%, 50/60 Hz
Dimensions: L 980 x W 580 x H 1200 mm
Weight: 280 KG
• Servo motorized cutter head
• High-quality belt, high-precision cable feeding
• Good quality high-speed steel make blades
• Fully covered safety guard with interlock sensor
• Low maintenance, user-friendly
