Stripping length:
Front side: Max 9.5 mm [Customizable]
Rear side: Max 13.5 mm [Customizable]
Wire range: AWG 30-AWG 22
Production rate: 800 pcs/h by 100mm cutting length
Twisting length: 2-10.5 mm [Customizable]
Cutting length (L): 65-1000 mm [Other lengths on request]
Power supply: AC 110V-220V ± 10%, 50/60 Hz
Tinning length: 0.5-13.5 mm
Rated power: 3500 W
Dimensions: L 2130 x W 1530 x H 1900 mm
Air supply: 0.5-0.8 MPa [ Clean and dry air]
Weight: 800KG
Detector: Terminal run-out, Wire run-out, Wire knot, Terminal crimping, Air pressure, Heating
