Function: Measure cable, feeding length, laying cable, automatic cut cable, twist cable tie. Feeding speed, winding speed, winding cycles, twisting cycles, cable tie cut length.
Wire Diameter: φ 1 - 15 mm [Customizable]
Cable Tie Length: 200 - 300 mm [Customizable]
Tying Diameter: 40-80 mm [Optional 8-30 mm / 18-45 mm]
Cable Roll Inner Diameter: 50-300 mm
Winding Speed: 1 - 10 cycles/s
Cable Tie Twist Cycle Time: 0.6 s
Cable Weight: 3 KG [Customizable to 50 KG]
Data Library: 100 programs
Display: 7" color touchscreen, English / Chinese [Other languages on request]
Compatible Peripherals: Cable prefeeding machine
Power Supply: AC 110 - 220 V ± 10%, 50 / 60 Hz
Air Supply: 0.4 - 0.7 MPa (clean and dry air)
Dimensions: L 1500 x W 610 x H 1100 mm
Weight: 150 KG
• Compact, free-standing, fully programmable and mobile device
• Wind wire, cable and wire rope into coils or onto spools
• Wind the required length of electrical, optical cables or other similar materials
• Automatic cable laying device synchronized with rotational motion
• Operation without constant, direct supervision
• Precise feeding, uniform laying
