Test Parameter: AC resistance, DC voltage
Display: 4.3 inch TFT LCD
Basic accuracy: Voltage: 0.03%+0.03%FS, Resistance: 0.2% FS
Range:
Resistance: 0.1μΩ ~3kΩ
Voltage: 10μV~200V
Signal source: AC 1kHz, Open circuit voltage <20mV, Test current <10mA
Ranges: 7 ranges automatic or manual
Test speed: 10 times/s, 30 times/s, 100 times/s
Display result: Direct reading value, Δ%
Correction: Short-circuit clear zero in full range
Comparator: PASS FAIL front panel LED display
Trigger: Internal trigger, manual trigger, external trigger, remote trigger
Interface: RS232, Handler
Power supply: Voltage: 198VAC～240VAC, Frequency: 50Hz, Power: Max.15VA
Dimension:
Shelf size (mm): 215 (W) * 88 (H) * 335 (D)
External dimensions (mm): 235 (W) * 105 (H) * 360 (D)
Others: Keyboard locks and data storage functions, internal flash memory and U disk records
Accessories: 505 Kelvin testing line
Options: 506A Test probe, 506 test stick
