Rated DC Output (0℃–40℃)
Voltage:0~80V
Current: 0~11A
Overvoltage Protection: 0.1~88V
Overcurrent Protection: 0.1~12A
Voltage Output
Power Effect: ≤0.01% + 4mV
Load Effect: ≤0.01% + 5mV
Recovery Time: ≤1.5ms (50% load change)
Ripple and Noise: 2mVrms, 30mVpp
Temperature Coefficient: ≤300ppm/℃
Setting Accuracy: ±(0.03% of reading + 10mV) (25±5℃)
Setting Resolution: 1mV
Current Output
Power Effect: ≤0.2% + 3mA
Load Effect: ≤0.2% + 5mA
Ripple and Noise: ≤10mArms
Setting Accuracy: ±(0.3% of reading + 10mA) (25±5℃)
Setting Resolution: 1mA
Display
Voltage: 5 digits display
Current: 5 digits display
Voltage Resolution: 1mV
Current Resolution: 1mA
Reading Accuracy: ±(0.02% of reading + 5mV) (25±5℃); ±(0.05% of reading + 10mA) (25±5℃)
Protection: Overload protection, reverse polarity protection, overvoltage protection, overcurrent protection, overtemperature protection
Lock Keyboard: YES
Interface: Standard RS232, supports SCPI instruction set, supports U disk storage, analog control interface
Memory Call-Up: 100 groups
Insulation: Between the output terminal and the cabinet or other terminals: 60VDC
Operating Environment: Indoor use, Altitude: ≤2000m, Environment temperature: 0~40℃, Relative humidity: ≤80%, Installation level: II, Pollution degree: 2
Storage Environment: Environment temperature: -10~70℃, Relative humidity: ≤70%
Power Input: AC 220V ±10%, 50/60Hz
Accessories: Manual, power cable, software, RS232 interface cable
Size: 412mm(D)*215mm(W)*89mm(H)
Weight: 5.5kg
Datasheet
Features
High accuracy and high resolution 1mV / 1mA
Small and light, with high power factor and high efficiency
Continuously adjustable to achieve the same 0-Vout as the linear power supply
Achieve low output ripple and noise comparable to linear power supplies
4.3 inch LCD segment code screen with high definition display
With output control switch, the control is more flexible
One-key lock function, effectively prevent misuse
It can store / recall 100 sets of voltage and current data, and can be executed regularly to achieve simple automatic test purpose
Remote sensing to compensate the voltage drop of the load line
Standard RS232 interface, programming instruction set conforms to SCPI
Optional analog control interface, battery charging function
