Capacity selection: 5,10,20,50,100,200,500 kg
Force measurement accuracy: within ± 1% of the indicated value
Display mode: LCD Chinese display, film touch key
Unit switch: Kg, lb, N
Data sampling frequency: 200times/ SEC
Resolution of the testing machine: the maximum load is 1/± 25,000 yards, the inside and outside are not classified, and the whole resolution is unchanged
Load sensors: Basic configuration: pull and pressure sensors (maximum load)
Effective test width: 150mm
Effective stretch space: 1200mm
Test speed range: 50-300mm/min stepless speed regulation and 5-gear constant speed (special test speed can be customized according to customer requirements)
Displacement measurement accuracy: within ± 1% of the indicated value
Breakpoint ratio setting: 0 ~ 99%, users can set the appropriate break down time according to different materials
Test bench safety device: up and down travel limit device
Overload protection: when the maximum load exceeds 10%, the machine will be automatically protected
Fixture configuration: One set of stretching fixtures
Host size: 550×400×1820mm
Main engine weight: about 100kg
Power supply: 220V/50Hz
