Marble table size (mm): 650*520
Glass table size (mm): 530*430
Movement stroke (mm): X:500mm Y:400mm
Focusing stroke (mm) (Z axis): 200mm
Measurement and aiming system:
High resolution camera (CCD)
Continuous zoom objective magnification: 0.7-4.5X
Working distance: 90mm
Video magnification: 20-230X
Display resolution: 0.0005mm
Precision Image 2D Measurement Software
Indication error: X.Y ≤ (3 + L/200) um (L is the measured length unit: mm)
Lighting system: The ring surface light source and the transmission light source are LEDs, and the brightness is adjustable.
Dimensions (mm) (length × width × height): 800*1000*1200
Instrument weight (kg): 300kg
Glass table bearing: 20kg
Instrument power: 220V（AC) 50HZ
