JISC IT-5 Torque Calibrator (5Nm)

Maximum Torque: 5Nm

Units: N.m, kgf.cm, lbf.in

Effective Range: ±0.02-±5Nm

Resolution: 0.001Nm

Accuracy: ±0.5%of F.S

Maximum Allowable Torque: 150%FS

Maximum Memory Data: 511

Comparator: Upper & Lower Limit Setting of Specification

A/D Convertor: 16bit

Response: 640Hz/sec

Battery Operated: Ni.MH Battery with Power Adaptor

Operating Temperature: 10~40 Deg C & Humidity of 85% RH & below

Data Output: RS 232C Interface

Dimension: W230 x H60 x D149

Weight: Approx. 3.3kg

CHARACTERISTICS

For the purpose of torque control without controlling angles.

Simple and handy testing can be performed for setting torque for electric drivers and measuring opening torque of cap of jar.
