Core: ARM Cortex M0
Data Rate: 500 kb/s
Frequency: 860 MHz to 943 MHz, 2.4 GHz
Dimensions: 22 mm x 22 mm x 2.8 mm
Modulation: 2-FSK/GFSK, 4-FSK/GFSK, ASK, OOK
Memory Size: 256 kB, 24 kB
Output Power: 8 dBm, 27 dBm
Interface Type: I2C, SPI, UART
Mounting Style: SMD/SMT
Moisture Sensitive: Yes
Protocol - Sub GHz: Sub GHz
Receiver Sensitivity: - 88 dBm, - 130 dBm
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 1.8 V
Operating Supply Voltage: 1.7 V to 3.6 V
Supply Current Receiving: 8.8 mA
Supply Current Transmitting: 15.1 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth
