Application
Scribing, Drilling
Surface treatment
Sheet metal cutting, Welding
Marking on fly
Metal surface processing, Peeling coating
Specification
M²: <1.5
Armored Cable Length (m): 3
Nominal Average Output Power (W): 60
Maximum Pulse Energy (mJ): 2
Pulse Repetition Rate Range (kHz): 1 ~ 4000
Pulse Duration (ns): 2 ~ 500
Output Power Stability (%): <5
Cooling Method: Air Cooled
Supply DC Voltage (VDC) (V): 24
Nominal Power Consumption (W): 230
Central Emission Wavelength (nm): 1064
Emission Bandwidth @3dB (nm): <15
Output Beam Diameter (mm): 7.0±1.0
Output Power Tuning Range (%): 0 ~ 100
Operation Temperature (℃): 0 ~ 40
Storage Temperature (℃): -10 ~ 60
Net Weight: 4.1 kg
Size(L×W×H): 253.3 x 205 x 75 mm
