Capacity of work tank: 1100x600x400mm
Work table size: 700x400mm
Longitudinal travel(X-axis): 400mm
Cross travel(Y-axis): 300mm
Z axis travel(Z-axis): 300mm
Distance between platen to table: 270~570mm
Max. Electrode weight: 100kgs
Max. Work piece weight: 1000kgs
Fluid tank capacity: 370L
Machine outside dimensions(WxDxH): 1900x1750x2350mm
Machine weight: 2250kgs
Max. Machining current: 60A; 90A(Optional)
Max. Power input: 7KVA; 10KVA
Max. Machining rate(mm3/min): 400; 600
Min. Electrode wear ratio: 0.12%
Best surface / Ra: Ra 0.2μm
Min. D. R. O. resolution(mm): 0.001mm
Generator weight: -
