Pitch: 2.5 mm (0.098 in)
Wire Gauge: 28 AWG to 20 AWG
Application: Wire-to-Board
Housing Color: Natural
Contact Gender: Pin (Male)
Current Rating: 3 A
Mounting Angle: Right Angle
Mounting Style: Through Hole
Number of Rows: 1 Row
Voltage Rating: 250 VAC/DC
Contact Plating: Tin
Contact Material: Copper
Housing Material: Polyamide (PA66)
Termination Style: Crimp
Number of Positions: 8 Position
Insulation Resistance: 1 MOhms
Termination Post Length: 3.2 mm (0.126 in)
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 25 C
