Performance Data Temperature
Temperature range [°C]: -70…180
Temperature variation depending on setpoint [± K]: 0.3…2.0
Temperature fluctuation depending on setpoint [± K]: 0.1…0.1
Average heating-up rate according to IEC 60068-3-5 [K/min]: 4.8
Average cooling down time according to IEC 60068-3-5 [K/min]: 4
Max. heat compensation at 25 °C [W]: 4500
Performance Data Climate
Temperature range [°C]: 10…95
Temperature fluctuation depending on setpoint [± K]: 0.1…1
Humidity range [% RH]: 10…98
Humidity fluctuation depending on setpoint: ≤2.5 ± % r.F.
Dew point temperature range [°C]: 5…94
Electrical data
Rated Voltage [V]: 400
Power frequency [Hz]: 50
Nominal power [kW]: 11
Unit fuse [A]: 32
Phase (Nominal voltage) [ph]: 3~
Outer dimensions
Width net [mm]: 1580
Height net [mm]: 2005
Depth net [mm]: 1140
Wall clearance back [mm]: 300
Wall clearance sidewise [mm]: 200
Viewing window width [mm]: 508
Viewing window height [mm]: 300
Doors
Unit doors: 1
Internal Dimensions
Width [mm]: 1200
Height [mm]: 1020
Depth [mm]: 600
Further Dimension
Interior volume [L]: 734
Net weight of the unit (empty) [kg]: 635
permitted load [kg]: 160
Load per rack [kg]: 40
Environment-specific data
Sound-pressure level [dB(A)]: 69
Fixtures
Number of shelves (std./max.): 1/11
