Load range [kN]: 5
Stiffness [kN/mm]: 11
Dimension
Width [mm]: 804
Height [mm]: 1305
Depth [mm]: 631
Weight [kg] approx.: 83
Technical characteristics
Working area depth [mm]: 420
Working area height [mm]: 970
max. test stroke (without tools, grips, adapter, load cell) [mm]: 1025
Cross head speed range [mm/min]: 0.0015 - 1200
Electrical data
Rated Voltage [V]: 230
Power frequency [Hz]: 50
Nominal power [kW]: 0.5
Phase (Nominal voltage) [ph]: 1~
