Power supply: 50kW
DC Output:
DC Output Rating:
Output Voltage: 60V
Output current : 834A
Constant voltage mode (CV):
Setting accuracy: 0.5% F.S.
Setting resolution: Below 100 V: 0.01 V; Over 100 V: 0.1 V
Input power fluctuation: Less than 0.05%
Load fluctuation *1: Less than 0.1%
Transient response recovery time *2: 12 ms or less
Ripple Voltage (RMS) : 0.4% FS or less
Noise Voltage (Peak): 2% FS or less
Rise time *3: 50 ms or less
Remote sensing Maximum compensation voltage: Compensates for voltage drops up to 5% of the rated voltage
Constant Current Mode (CC):
Setting accuracy: 0.5% FS . (1% rated current or more)
Setting resolution: Below 100 A: 0.01 A; Over 100 A: 0.1 A
Constant Power Mode (CP):
Setting accuracy: P=V*I (calculated value)
Setting resolution: 0.01 kW
Measurement features:
DC voltage measurement:
Measurement accuracy: 0.5% F.S.
Resolution: Below 100 V: 0.01 V; Over 100 V: 0.1 V
DC current measurement:
Measurement accuracy: 0.5% FS . (1% rated current or more)
Resolution: Below 100 A: 0.01 A; Over 100 A: 0.1 A
DC power measurement:
Measurement accuracy: P=V*I (calculated value)
Resolution: 0.01 kW
General Specifications:
Power supply:
Input Rating: Three-phase three-wire GND
Input voltage/ frequency: AC 380 V to 400 V ±15 % / 47 to 63 Hz (option: AC 200 V/208 V/415 V/440 V/480 V)
Power factor (at maximum load): Over 90%
Efficiency (at maximum load): When the input voltage is 380 V to 400 V: 87% or more; When the input voltage is 200 V/208 V/415 V/440 V/480 V: 84% or more ;
Input power (three-phase, three-wire: AC 380 V): At maximum load: 66 kVA or less
Input current (three-phase, three-wire: AC 380 V): 100 A or less
Mass (Body only): 225 kg; Input voltage: 200V/208V/415V/440V/480V 420 kg
