Rated Value
(0°–40°C)
Input Voltage 0–500 V 0–500 V
Input Current 0–3 A 0–30 A
Input Power 750 W 750 W
Min. Operating
Voltage 0.36 V / 3 A 3.6 V / 30 A
Constant Voltage
Mode
Range 0–50 V 0–500 V
Resolution 1 mV 10 mV
Accuracy ±(0.025% + 0.05% FS) ±(0.025% + 0.05% FS)
Constant Current
Mode
Range 0–3 A 0–30 A
Resolution 0.1 mA 1 mA
Accuracy ±(0.05% + 0.05% FS) ±(0.05% + 0.05% FS)
Constant
Resistance Mode 1
Range 0.15 Ω–10 Ω 10 Ω–7.5 kΩ
Resolution 0.001 Ω 0.1Ω
Accuracy 2 0.01% + 0.08 S 0.01% + 0.0008 S
Constant Power
Mode 3
Range 750 W 750 W
Resolution 10 mW 10 mW
Accuracy 0.2% + 0.2% FS 0.2% + 0.2% FS
Dynamic Mode
CC Mode
T1 & T2 20 µs–3600 s; Res: 1 µs 20 µs–3600 s; Res: 1 µs
Accuracy 5 µs ± 100 ppm 5 µs ± 100 ppm
Ascending/
Descending
Slope 4
0.0001–0.1 A/µs 0.001–1 A/µs
Minimum Rise
Time 5 ~20 µs ~20 µs
Measuring Range
Readback Voltage
Range 0–50 V 0–500 V
Resolution 1 mV 10 mV
Accuracy ±(0.025% + 0.025% FS) ±(0.025% + 0.025% FS)
Readback Current
Range 0–3 A 0–30 A
Resolution 0.1 mA 1 mA
Accuracy ±(0.05% + 0.05% FS) ±(0.05% + 0.05% FS)
Readback Power
Range 750 W 750 W
Resolution 10 mW 10 mW
Accuracy ±(0.2% + 0.2% FS) ±(0.2% + 0.2% FS)
Protection Range
Overpower Protection ~760 W ~760 W
Overcurrent Protection ~3.3 A ~33 A
Overvoltage Protection ~530 V ~530 V
Over Temperature Protection ~85°C ~85°C
Specification
Short Circuit
Current (CC) ~3.3 / 3 A ~3.3 / 30 A
Voltage (CV) 0 V 0 V
Resistance (CR) ~120 mΩ ~120 mΩ
Input Terminal Impedance 1 MΩ 1 MΩ
Dimensions 482mm × 131.4mm × 580mm
Net Weight: 24.95kg.
Accessories Supplied
Quick Start Guide
Documentation CD
Power cord
ACCESSORIES AVAILABLE
2380-001 9-pin Rear Panel Mating Connector
2380-002 DUT Connection Protective Cover
7007-2 Double-Shielded Premium IEEE-488 Interface
Cable, 2m (6.5 ft)
KP-CL-488LPA IEEE-488.2 Interface Board for the PCI Bus
USB-B-1 USB Cable, Type A Connector to Type B
Connector, 1m (3.3 ft)
RACK MOUNT KITS FOR THE 2380-500-15 AND
THE 2380-120-60
4299-7 Universal Fixed Rack Mount Kit
RMU2U Fixed Rack Mount Kit
386759800 RMU2U Rack Mount Cosmetic Filler Panel
RACK MOUNT KIT FOR THE 2380-500-30
2380-RM Full-Rack-Width Instrument Fixed
Rack Mount Kit
