MAXIMUM POWER: 195W
LOAD REGULATION:
Voltage: ≤0.02% + 4mV
Current: ≤0.2% + 3mA
LINE REGULATION:
Voltage: ≤0.02% + 4mV
Current: ≤0.2% + 3mA
RIPPLE AND NOISE (20Hz–20MHz):
Voltage: ≤1mVrms/≤5mVp-p
Current: ≤6mArms
SETTING RESOLUTION:
Voltage: 10mV
Current: 1mA
SETTING ACCURACY:
Voltage: ≤0.06% + 20mV
Current: ≤0.2% + 10mA
READBACK RESOLUTION:
Voltage: 10mV
Current: 1mA
READBACK ACCURACY:
Voltage: ≤0.06% + 20mV
Current: ≤0.2% + 10mA
MEMORY: 30 setup memory locations.
OUTPUT TIMER RANGE: 0.1s to 99999.9s.
DISPLAY: Vacuum fluorescent display.
CONNECTIONS:
Front: Power output jacks: 3-sets, safety-shrouded
banana jacks.
Rear: DB9 connector for remote control,
OVERTEMPERATURE PROTECTION: If the internal
temperature of the supply exceeds 85°C, the supply will
automatically turn off.
EMC COMPLIANCE: Conforms to European Union EMC
Directive.
SAFETY COMPLIANCE: Conforms to European Union Low
Voltage Directive.
POWER LINE RATINGS: 110VAC/230VAC ±10%.
POWER LINE FREQUENCY: 47Hz–63Hz.
MAXIMUM POWER CONSUMPTION: 750VA.
OPERATING ENVIRONMENT: 0° to 40°C, 5% to 80% relative humidity at up to 40°C.
STORAGE ENVIRONMENT: –20° to 70°C, 5% to 80%
relative humidity up to 40°C, and 5% to 60% relative
humidity from 40° to 70°C.
PHYSICAL CHARACTERISTICS
Height: 88.2 mm ( 3.5 in)
Width: 214.5 mm ( 8.5 in)
Depth: 354.6 mm (14 in)
Net Weight: 7.10kg (15.7 lbs.).
Shipping Weight: 9.40kg (20.7 lbs.).
