Width: 29 mm (1.142 in)
Height: 29 mm (1.142 in)
Length: 31.5 mm (1.24 in)
Tolerance: 5 %
Dielectric: Polypropylene (PP)
Capacitance: 0.39 uF
Lead Spacing: 27.5 mm (1.083 in)
Lead Diameter: 0.8 mm
Capacitance - nF: 390 nF
Capacitance - pF: 390000 pF
Termination Style: Radial
Voltage Rating AC: 500 VAC
Voltage Rating DC: 1.6 kVDC
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 55 C
