- High Resolution
- True RMS AC, DC
- Display resolution 30,000
- AC bandwidth: 100Khz
- Voltage DC:
30.000mV, 300.00mV, 3.000V,
30.000V, 300.001V, 1000.0V/ 0.05%
- Voltage AC (True RMS):
30.000mV, 300.00mV, 3.000V,
30.000V, 300.001V, 1000.0V / 0.6%
- Voltage AC +DC (True RMS):
30.000mV, 300.00mV, 3.000V,
30.000V, 300.001V, 1000.0V / 0.7%
- Current DC:
300.00 μA, 3000.00 μA, 30.000 mA,300.00 mA /0.2%
3.0000 A, 10.000 A /0.3%
- Current AC (TrueRMS):
300.00μA, 3000.00μA, 30.000mA, 300.00mA /0.6%
3.0000 A, 10.000 A /0.8%
- Current AC+DC (True RMS):
300.00 μA, 3000.00 μA, 30.000 mA,
300.00 mA, 3.0000 A, 10.000 A /0.9%
- Resistance:
30.000Ω, 300.00Ω, 3.0000kΩ, 30.000kΩ, 300.00 kΩ / 0.2%
3.0000MΩ, 30.000MΩ, 100.00MΩ, 300.00 MΩ, 300.00 nS /0.6%
- Diode: Yes
- Capacitance: 1
0.000nF, 100.00nF, 1000.0nF, 10.000μF,
100.00μF, 1000.0μF, 10.000mF /1%
- Frequency: 99.999-999.99Hz / 0.05%
- Thermocouple type: J (-200 to 1372oC), K(-210 to 1202oC)/ 1% (Option type J)
- % Sacle 4-20mA: Yes
- Low pass low filter: Yes
- Z low – low impedance mode: Yes
- Smart Ω: Yes
- OLED display: Yes
- Manual data logging: yes
- PC connectivity: IR-USB (option)
- Connectivity: IR-to-Bluetooth (option)
- Dust and water resistant casing: IP 54
Power supply: 4 pin AAA
Dimensions: 207.0x92.0x59.0
Included Accessories: Test lead set; K-type thermocouple and adapter; Quick start guide; Batteries; Test report; Certificate of calibration
Datasheet
Brochures
Optional Accessories
U1182A: Surface probe, industrial
U1583B: AC current clamp
U1186A: Thermocouple (K-type, 1m) and adapter
U1185A: Thermocouple (J-type) and adaptor
U1184A: Adaptor, temperature probe
U1183A: Probe, air
U1181A: Immersion probe type K
U1180A: T/C adapter + lead kit, J and K type
U1177A: Infrared (IR)-to-Bluetooth class 2 (10meter) adapter
U1176A: LED flash light
U1174A: Carrying case, soft
U1172A: Transit case for handheld DMM, aluminum-clad
U1171A: Magnetic hanging kit
U1169A: Test Probe Leads (with 19-mm tips and 4-mm tips)
U1164A: Test probes, fine tip
U1163A: Grabbers, SMT
U1162A: Alligator clip
U1168B: Test lead kit
U1117A: Infrared (IR)-to-Bluetooth class 1 (100meter) adapter with Mfi
U1115A: Bluetooth class 1 (100meter) remote logging display
U1118A: Remote connectivity kit (100meter) with U1115A and U1117A
U1173B: IR-USB cable, all U1200 series handheld multimeter VOLT: DC 3.3V - 5V
