Digits of Resolution: 4 ½ digits
Display Type: 7-segment LCD
Reading Speed: 40 readings/s
Basic 1-Year DCV Accuracy: 0.025%
Vsense alerts in the presence of high AC voltage
Built-in square-wave generator
Measurement Functions: DCV; ACV; DCI; ACI; Resistance; Frequency; Capacitance; Diode test; Temperature, Continuity test with visual and audio alerts
Battery Life: 800 hours, 4 x 1.5 V AA
Connectivity: IR to USB or Bluetooth
60,000 counts resolution on dual display and high basic DCV accuracy
Display resolution: 60,000 counts
True RMS: AC + DC
Voltage DC : 60 mV to 1000 V/ 0.025 % + 5 cnts
Voltage AC: 60 mV to 1000 V/ 0.3 % + 25 cnts
Current DC: 600 µA to 10 A/ 0.05 % + 5 cnts
Current AC: 600 µA to 10 A/ 0.6 % + 25 cnts
Resistance: 600 Ω to 60 MΩ/ 0.05 % + 2 cnts
Frequency: 99.999 Hz to 9.9999 MHz/ 0.005 % + 3 cnts
Temperature: J, K-type
Operating temperature: –20 °C to 55 °C
Ingress protection rating: IP-67
Dimensions (W x H x D): 218 x 96 x 59 mm
Weight: 701 grams
Included accessories: Power cord, Quick guide, Calibration certificate, IR-to-USB Cable, Batteries
