Operating voltage (DC): 10 V to 1000 V
Power: 1000 W
Current: 20 A
Constant current (CC) mode
Operating range: 0 A to 20 A
Setting range: 0.0000 A to 20.2000 A
Setting accuracy: ±(0.2 % of setting + 0.1 % of rating)
Constant resistance (CR) mode:
Setting range
H range: 505.00 mS to 0.00 S
L range: 5.0500 mS to 0.0000 S
Setting accuracy:
H range ±(0.5 % of setting + 0.5 % of rating)
L range ±(0.5 % of setting + 0.2 % of rating)
Constant voltage (CV) mode
Setting range: 0.00 V to 1010.00 V
Resolution: 0.02 V
Setting accuracy: ±(0.05 % of setting + 0.05 % of rating)
Constant power (CP) mode
Operating range: 0 W to 1000 W
Setting range: 0.00 W to 1010.00 W
Setting accuracy: ±(0.5 % of rating + 0.02 A × Vin)
Arbitrary I-V characteristics (ARB) mode
Response speed: 500 μs, 1 ms, 2 ms, 5 ms, 10 ms, 20 ms, 50 ms, 100 ms, or off
Measurement function: V, A, P
Pulse function: Frequency setting range 1.0 Hz to 10.0 kHz
Other functions: Alarm, Sequence, Cutoff function, Integration display, Remote sensing
Communication: GPIB (option), RS232C, USB, LAN
Accessories:
Power cord (1 pc., length: 2.5 m), Safety terminal adapterTL41 (red 1 set, black 1set), External control connector kit (1 set), Safety Information (1 copy), Setup Guide (1 copy), Quick Reference(Japanese 1 sheet, English 1 sheet), CD-ROM (1 disc)
