Operating voltage (DC): 1.5V ~ 150 V
Current:
-H: 15A/75W
-M: 1.5A/75W
-L: 150mA/22.5W
- CC mode
Operating range:
Range H: 0 A ~ 15A
Range M: 0 A ~ 1.5A
Range L: 0 A ~ 150mA
Setting accuracy: ±(0.2 % of set + 0.2 % of f.s) + Vin/ 500 kΩ
Ripple: rms: 7.5 mA/ p-p: 50mA
- CR mode
Setting range
H: 0 S ~ 10 S
M: 0 S ~ 1 S
L: 0 S ~ 100 mS
Setting accuracy: ±(0.5 % of set + 0.5 % of f.s) + Vin/ 500 kΩ
- CV mode
Operating range:
H: 0 V ~ 150 V
L: 0 V ~ 15 V
Setting accuracy: ±(0.1 % of set + 0.1 % of f.s)
Measurement function: V, A, P
Other functions: Sequence, Remote sensing, Protection function (OVP, OCP, OPP, UVP, OHP)
Communication: GPIB, RS232C
Accessories:
Rear load in terminal cover: 1pc
Set of screws for the load input connector: 2 sets (M6 bolt, M6 nut, M6 spring washer, M4 screw)
Load unit attachment screws: 2 pcs (M3-10 screws, attached to the unit)
Sensing terminal screw on the rear panel: 2 pcs (M3-6 screws, attached to the unit)
