Pink noise or sine wave 1000 Hz (not at the same time)
Two output channels when testing
The channels can be phase shifted to 0° or 90°
Fine adjustments of output voltage
RCA and 4 mm banana type output connectors
Audio-cables for test object included (RCA and 3,5 mm phono)
Output signal according to IEC 60065 Annex C, fig. C1 (IEC60268)
Amplitudes of sine wave and pink noise according to table below:
Output Voltage/ Sine wave 1 kHz/ Filtered pink noise
Low/ 0-100 mV/1 kohm/ 0-35 mV rms/1 kohm
Medium/ 0-1 V/1 kohm/ 0-350 mV rms/1 kohm
High/ 0-5 V/1 kohm/ 0-1.7 V rms/1 kohm
Weight: 4kg
Dimensions: 290x270x60 Mm (LxWxH)
Supply: 220 VAC 50 Hz
