Voltage signal input: Direct input
Resistance: >2MΩ, 20pF
Testing range: 10~700Vrms
Peak voltage: 1000V
Power consumption: <0.5VA/phase
Current input circuit
Indirect input, with different current clamps
Testing range: 20Arms, 500Arms, 1000Arms
Power consumption: <2.0VA/phase
Frequency range: 40 Hz ~70Hz
Power factor: 0.00～1.00 ±0.005
Measurement accuracy: 0.5
Screen and memory
Screen: 640×480, 3.5’ TFT LCD touch-screen
Internal Memory: 16 MB Flash
External Memory:4GB
Com port: USB port
Power supply: Rechargeable Li-ion battery
Workable for 5~6 hours
Power adaptor: AC100~240V/DC16.8V-1A adaptor
Main unit: 0.7kg, 277×169×36mm
Working temperature: -20~40℃
Relative humidity: 5~90%RH
Insulation: >2MΩ, AC1500V/50Hz, 1 min
