Illumination/viewing system
Reflectance: di:8°, de:8° (diffuse illumination: 8° viewing) / SCI (specular component included) / SCE (specular component excluded) switchable
Conforms to CIE No. 15, ISO 7724/1, ASTM E 1164, DIN 5033 Teil 7, and JIS Z 8722 (Condition c)
Transmittance: di:180° (diffuse illumination: 180° viewing)
Integrating sphere size: Ø152 mm
Detector: Dual 40-element silicon photodiode arrays
Spectral separation device: Planar diffraction grating
Wavelength range: 360 nm to 740 nm
Wavelength pitch: 10 mm
Half bandwidth: Approx. 10 nm
Measurement range: 0 to 175 % (Reflectance or transmittance); Output/display resolution: 0.01%
Light source: Pulsed xenon lamp
Measurement time: Approx. 1 s (to data display/output); Minimum measurement interval: Approx. 3 s
Measurement/ illumination area
Reflectance: Changeable by changing mask and settings.
LAV: Ø30 mm/Ø36 mm; MAV (optional): Ø8 mm/Ø11 mm; SAV (optional): Ø3 mm/Ø6 mm
Transmittance: Ø20 mm
Repeatability: Spectral reflectance: Standard deviation within 0.1% (400 nm to 740 nm) Chromaticity value: Standard deviation within ΔE*ab 0.04
* When a white calibration plate is measured 30 times at 10-second intervals after white calibration
Inter-instrument agreement: Within ΔE*ab 0.15 (Typical)
(Based on 12 BCRA Series II colour tiles compared to values measured with a master body at 23°C)
Transmittance chamber: No sides (unlimited sample length); Depth (maximum sample thickness): 60 mm Sample holder (optional) for holding sheet samples or containers of liquid samples can be installed/removed
Display: 5.7-inch TFT colour LCD
Display languages: English, Japanese, German, French, Italian, Spanish, Simplified Chinese
White calibration: Automatic white calibration (reflectance)/100% calibration (transmittance) using internal white calibration plate
(Not available when using petri dish or transmittance cell)
Interfaces: USB 1.1 (Connection to PC; USB memory stick); RS-232C standard (Connection to serial printer)
Observer: 2° Standard Observer or 10° Standard Observer
Illuminant: A, C, D50, D65, F2, F6, F7, F8, F10, F11, F12, ID50, ID65 (simultaneous evaluation with two light sources possible)
Displayed data: Spectral values, spectral graph, colorimetric values, colour-difference values, colour-difference graph, pass/fail judgment, pseudo colour, colour assessment
Colour space: L*a*b*, L*C*h, Hunter Lab, Yxy, XYZ, Munsell, and colour differences in these spaces (except for Munsell)
Index
Reflectance: MI; WI (ASTM E 313-73, ASTM E 313-96); YI (ASTM E 313-73, ASTM E 313-96, ASTM D 1925); ISO Brightness, B (ASTM E 313-73)
Transmittance: Gardner, Iodine, Hazen (APHA), European Pharmacopoeia, US Pharmacopeia
User index: User-defined index
Color-difference equation: ΔE*ab (CIE 1976), ΔE*94 (CIE 1994), ΔE00 (CIE 2000), ΔE (Hunter), CMC (l: c)
Pass/fail judgment: Tolerances can be set to colorimetric values (except Munsell), colour-difference values, or reflectance index values
Storable data: Sample data: 4,000 measurements; Target colour data: 1,000 measurements
USB memory stick storage: Storage of measurement data and target colour data. Storage/reading of measurement condition settings
(Security-enabled USB memory sticks cannot be used.)
Power: AC 100 to 240 V, 50/60 Hz (using exclusive AC adapter)
Size: Slide cover closed: 385 (W) × 192 (H) × 261 (D) mm
Slide cover open: 475 (W) × 192 (H) × 261 (D) mm
Weight: Approx. 5.8 kg
Operating temperature/ humidity range: 13 to 33°C, relative humidity 80 % or less (at 35°C) with no condensation
Storage temperature/ humidity range: 0 to 40°C, relative humidity 80 % or less (at 35°C) with no condensation
Included:
Target Mask 30mm CM-A197
Dust cover CM-A191
Ground cable CM-A211
AC Adapter
USB Cable IF-A19
Transmittance Mask CM-A200
Instruction Manual
Inspection Certificate
