Product Parameters:
AC current source
Amplitude range: 6 × (0-30A) Accuracy: 0.2%
Six-phase current parallel output max: 180A
Phase current long-term allowable working values: 10A
Power: 260VA / phase
DC current source
phase power: 180VA
phase accuracy: 0.2%
AC voltage source
Amplitude range: 6 × (0-120V) Accuracy: 0.2%
Line voltage range: 0--240V
Phase voltage / line voltage Output power: 70VA / 140VA
DC voltage source
Phase voltage output amplitude: 0~± 160V Accuracy: 0.2%
Line voltage output amplitude: 0~± 320V
Phase voltage / line voltage Output power: 80VA / 160VA
Switch Terminals
switch input terminals: 8 pairs
Air access point: 1--20mA, 110V internal device active
Potential flip: 0-6VDC low 10-250VDC high
Switch output terminals: four pairs of empty contacts
breaking capacity: AC:250V / 0.5A; DC:60V / 0.5A,
Max. measurement time : 9999s
