Gain: 2.5 dBi, 4.4 dBi
VSWR: 2:1
Style: T-Bar Flex
Width: 8.5 mm
Height: 1.6 mm
Length: 35.2 mm
Impedance: 50 Ohms
Cable Type: 100 mm RF1.13
Application: Embedded Design, Cellular, Headsets, Tablets, Gateway, Access Point, Handheld, Telematics, Tracking, Healthcare, M2M, Smart Grid, OBD-II
Unit Weight: 800 mg
Cable Length: 100 mm
Polarization: Linear
Power Rating: 500 mW
Mounting Style: Adhesive Mount
Electrical Type: Embedded
Number of Bands: 2 Band
Center Frequency: 2.4425 GHz, 7.25 GHz
Mechanical Style: PCB Trace
Maximum Frequency: 5.825 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Antenna Connector Type: U.FL
Protocol - WiFi - 802.11: WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
