Gain: 2.9 dBi, 4.3 dBi
VSWR: 2.5:1
Style: I-Bar Flex
Width: 25.1 mm
Height: 0.2 mm
Length: 53.6 mm
Impedance: 50 Ohms
Cable Type: 7.6 mm RF1.13
Technology: Cellular, LTE
Application: Medical Applications, Home Automation, Smart Metering, MWM, Firstnet, Automotive, Healthcare, POS, Tracking
Unit Weight: 4.064 g
Cable Length: 25 mm
Polarization: Linear
Power Rating: 2 W
Mounting Style: Adhesive Mount
Electrical Type: Embedded
Number of Bands: 8 Band
Center Frequency: 700 MHz, 750 MHz, 850 MHz, 900 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2700 MHz
Mechanical Style: PCB Trace
Maximum Frequency: 2.69 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Antenna Connector Type: U.FL
Protocol - WiFi - 802.11: LoRa, SigFox, LPWA, RPMA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), Cat-M
