KYORITSU KT171 Voltage Tester (12 - 690V AC/DC)

Voltage Test
- Voltage Range: 12 - 690V AC/DC
- LED
+ Nominal Voltage: 12/24/50/120/230/400/690V; AC (16 - 400Hz), DC (±)
+ Light on at more than: 7±3V (12V LED); 18±3V (24V LED); 37.5±4V (50V LED); 75%±5% of nominal voltage; (120/230/400/690V LED)
+ Response Time: <0.6s at="" 100="" of="" each="" nominal="" voltage="" br=""> - LCD
+ Range/Resolution (Auto-range): 300V AC/DC (6.0 - 299.9)/0.1V; 690V AC (270 - 759)/1V; 690V DC (270 - 710)/1V
+ Accuracy (23±5ºC): ±1.5V (7 - 100V); ±1%±5dgt (100 - 690V); AC (16 - 400Hz), DC(±)
+ Over limit Indication: "OL"
+Response Time: Approx. 1s at 90% - 110% of each voltage
- Peak Current: ls<3.5ma at="" 690v="" br=""> - Measurement Duty: 30s ON (operation time); 240s OFF (recovery time)
Single-pole Phase Test
- Voltage Range: 100 - 690V AC (50/60Hz)
Phase Rotation Test
- System: Three-phase 4-wire system; 200 - 690V phase-to-phase AC (50/60Hz)
- Phase Range: 120±5 degree
Continuity Test
- Detection Range: 0 - 400kΩ+50%
- Test Current: Approx. 1.5μA (battery 3V, 0Ω)
General
- Operating temperature and humidity ranges: -15 - 55ºC, max 85% RH (No Condensation)
- Storage temperature and humidity ranges: -20 - 60ºC, max 85% RH (No Condensation)
- Applicable Standards: IEC 61243-3, IEC 61010-1, IEC 61010-031, IEC 61557-7; CAT Ⅲ 690V / CAT Ⅳ 600V Pollution degree 2
- IP Rating: IP65 (IEC 60529)
- Power Source: LR03 (AAA) 1.5V×2
- Dimensions: 246(L)×64(W)×26(D) mm
- Weight: 190g (including batteries)
- Accessories: LR03 (AAA) 1.5V×2, KTA01 (4mm metal tips [2pcs/set]),KTA02 (4mm rubber caps [2pcs/set]), Instruction manual
