| AC A (50/60Hz) | 4/40mA/100A |±1%rdg±5dgt (4/40mA) |±1%rdg±5dgt (0~80A) |±5%rdg (80.1~100A) |
| AC A (WIDE) | 4/40mA/100A |±1%rdg±5dgt [50/60Hz], |±2.5%rdg±10dgt [20Hz~1kHz] (4/40mA) |±1%rdg±5dgt [50/60Hz], |±2.5%rdg±10dgt [40Hz~1kHz] (0~80A) |±5%rdg [50/60Hz], |±10%rdg [40Hz~1kHz] (80.1~100A) |
| Frequency Response | 20Hz~1kHz (40Hz~1kHz:100A) |
| Maximum Circuit Voltage | 600V AC/DC (between line/neutral) 300V AC/DC (against earth) |
| Conductor Size | Ø40mm max. |
| Safety Standard | IEC 61010-1 CAT.III 300V Pollution Degree 2 IEC 61010-2-032 |
| Effect of External Stray Magnetic Field | 2mA AC approx. in proximity to a 15mm-dia conductor carrying 100A AC |
| Withstand Voltage | 3700V AC for 1 minute |
| Response Time | Approx. 2 seconds |
| Power Source | Two R03 or equivalent (DC1.5V) batteries |
| Dimensions | 185(L) × 81(W) × 32(D)mm |
| Weight | 290g approx. |
| Accessories | 9052 (Carrying Case) R03 (1.5V) × 2 Instruction Manual |
| Optional | 8008 (Multi-Tran)* |
