KYORITSU 3166 Insulation Resistance Gauge

Insulation Resistance

DC Test Voltage1000V

Max. Effective

Scale Value: 2000MΩ

Mid-Scale Value: 50MΩ

First Effective

Measuring Range

Accuracy: 2~1000MΩ

|±5% rdg

Second Effective

Measuring Range

Accuracy: 0.5/1000MΩ

|±10% rdg

AC Voltage: 600V

Accuracy: |±3% of full scale value

Withstand Voltage: 3700V AC for 1 minute

Power Source: R6P (AA) (1.5V) × 4

Dimensions: 90(L) × 137(W) × 40(D)mm

Weight: 330g approx.

Accessories: 7025 (Test leads)

9067 (Pouch for test lead)

Neck Strap

R6P (AA) × 4

Instruction Manual

Manual
