- Class Ⅰ Test
• Protective conductor resistance
(Test current 200mA DC nominal)
• Insulation resistance test (250V or 500V)
• Leakage current test (100-253V/50Hz)
• Load current test (100-253V/50Hz)
- Class Ⅱ Test
• Insulation resistance test (250V or 500V)
• Leakage current test (100-253V/50Hz)
• Load current test (100-253V/50Hz)
- Extension Lead Test
• Protective conductor resistance (Test current 200mA DC nominal)
• Insulation resistance test (between Line/Neutral-Earth short, Line/Neutral)
• Leakage current test (100-253V/50Hz)
• Polarity test
- RCD Test : (10mA/30mA)
- Mains voltage indlcation
Display range : 30V-270V
Accuracy : ±5V
- Protective conductor resistance test
Measuring range : 0.00-20.00Ω
Open circuit voltage : 5V±0.4V DC
Measuring current : 200mA DC(nominal value)
Accuracy±3%rdg±5dgt
- Insulation resistance test
Rated volatge : 250V500V
Measuring range : 0.00-20.00MΩ
No-load voltage : 250V DC +20%,-0%500V DC +20%,-0%
Short circuit current : 1.5mA DC or less
Accuracy : ±2%rdg±3dgt
- Load current/Leakage current test
Load current
Mains voltage range : 100-253V/50Hz
Measuring range : 0.10-10.00A rms
Accuracy ±10%rdg±5dgt
Leakage current : 0.10-20.00mA rms
Accuracy : ±3%rdg±5dgt
- RCD test
Rated voltage : 230V -15% - +10%/50Hz
Rated current : 10mA/30mA
Function : × 1 (0.0ms-500.0ms)
× 5 (0.0ms-40.0ms)
Operating time accuracy±2ms(≦40ms),±8ms(>40ms)
- General
Power source : LR6(AA)(1.5V) × 6
Applicable StandardsIEC/EN61010-1 CAT II 300V, IEC/EN61010-2-030,
IEC/EN61010-031, EN61326-2-2, AS/NZ3760
Dimensions / Weight : 261(L) × 104(W) × 57(D)mm / Approx. 930g(including batteries)
Included Accessories
+ 7277(Mains lead),
+ 7129A(Test lead with Alligator clip),
+ 7161A(Flat test prod),
+ 7276(Adaptor for Extension cord),
+ 9193(Carrying case),
+ 8928(Fuse[10A/250V]),
+ 9121(Shoulder strap),
Buckle, LR6(AA) x 6, Instruction manual
- Optional Accessories
+ 8263-USB(USB cable with "KEW Report(software)"),
+ 7275(Printer cable:Mini Din 6pin-D-sub 9pin),
+ 7248(Test lead with Alligator clip and Flat test probe)
