- Wiring connections:1P2W, 1P3W, 3P3W, 3P4W
- Measurements and parameters: V, A, F, P, Q, S, KWh, KVARh, KVAh, PF (cos θ), Neutral current, Demand, Harmonics, Quality (Swell/Dip/Interruption, Transients/Over voltage, Inrush current, Unbalance rate), Capacitance calculation for PF correction unit, Flicker
- Voltage (RMS): 600.0 / 1000V
- Current (RMS)
Option 8128 ( 50A type ): 5 / 50A / AUTO
Option 8127 (100A type ): 10 / 100A / AUTO
Option 8126 ( 200A type ) : 20 / 200A / AUTO
Option 8125 ( 500A type ) : 50 / 500A / AUTO
Option 8124/8130 ( 1000A type ) : 100 / 1000A / AUTO
Option 8146/8147/8148 ( 10A type ) : 1 / 10A / AUTO
Option 8129 (3000Atype ) : 300 / 1000 / 3000A
- Active power: Accuracy 0.3%rdg±0.2%f.s.
- Frequency meter range: 40~70Hz
- Power supply (AC Line) AC100~240V / 50~60Hz / 7VA max
- Power supply (DC battery): Alcaline size AA battery LR6 or Ni-MH (HR-15-51) × 6
- Internal memory: FLASH memory (4MB)
- PC card interface : SD card (2GB)
- PC communication interface:USB Ver2.0, Bluetooth Ver2.1 + EDR Class2
- Display:320 × 240 (RGB) Pixel, 3.5inch color TFT display
- Display update period: 1 sec
- Applicable standards
IEC 61010-1 CAT IV 300V, CAT III 600V, CAT II 1000V Pollution degree 2
IEC 61010-2-030, IEC 61010-031, IEC 61326, EN 50160
IEC 61000-4-30 Class S, IEC 61000-4-15, IEC 61000-4-7
- Dimension: 175(L) × 120(W) × 68(D) mm
- Weight: Approx. 900g
- Included accessories: 7141B (Voltage test lead), 7170 (Power cord), 7219 (USB cable), 8326-02 (SD card 2GB), Carrying case
Input terminal plate × 6, KEW Windows for KEW 6315 (software), Calibration Certificate, Quick manual, Alkaline size AA battery (LR6) × 6
