Conductor size: Ø40mm
Rated current: 10A (rms) AC (14.1Apeak)
Output voltage: 500mV AC/10A AC
Accuracy: ±1.0%rdg±0.025mV (40Hz - 70Hz)
±4.0%rdg±0.025mV (30Hz - 5kHz, with inputs of 100mA or more)
Phase shift: within 1.0%
(45 - 70Hz while combining with KEW 5050, under the input of 10% or more of KEW 5050 leakage current range)
Cable length: Approx. 3m
Output connector: MINI DIN 6pin
Output impedance: Approx. 100W or less
Applicable standards: IEC 61010-1, IEC 61010-2-032
CAT Ⅲ 300V Pollution degree 2, IEC 61326-1
Operating temperature & humidity range: -10 - 50°C, relative humidity: 85% or Less (no condensation)
Dimensions: 128(L) × 81(W) × 36(D)mm
Weight: Approx. 280g
Optional Accessories: 9095 (Carrying case), Instruction manual, Ca
