General
Measurable Materials: Semi-hard materials and Cemented Carbides
Measurable Quantities: Msat, Hc, Jsat, weight-specific saturation moment (σsat), %Co
Main Cabinet
Accuracy: Gaussmeter: 0.25% reading + 0.1% range; Probe: 0.5% linearity
Resolution: 0.1 Oe (300 Oe range), 1 Oe (3000 Oe range)
Hc Measurement: Accuracy: ±2% for Hc > 500 A/m
Ms Measurement: Accuracy: ±2% on readin; Resolution: 10⁻⁴ µWbm (10⁻¹⁰ Tm³, 10⁻¹ emu)
Sample Size
With Coil 5800 MC-1: Ø 37 mm x H 19 mm (1.45” dia x 0.75” H)
With Coil 5800 MC-2: Ø 27 mm x H 13.6 mm (1” dia x 0.6” H)
Poles Diameter: 100 or 120 mm (4” or 4.7”)
Accuracy: Max H Field
With LP-100 mm Pole: 9700 Oe (776 kA/m)
With LP-120 mm Pole: 7750 Oe (620 kA/m)
Test Time: 1 minute (typical)
Operating Temperature Range: 10°C to 35°C
Communication Port: RS-232 / USB2
Main Electrical Cabinet
Power Supply: 220V, 50/60 Hz
Dimensions: 535 x 655 x 550 mm (21 x 26 x 22”)
Weight: 58.5 kg (129.3 lb)
Fluxmeter
Ranges: (1,2,5,10,20,50,100) x 2000 µWb
Resolution: From 1 µWb (range 1) to 100 µWb (range 100)
Accuracy: ±0.5%
Drift: 10 kΩ x range
Communication: RS232 / USB
