Capacity: 20 L
Stirring Positions: 1
Speed Range: 100-1500 rpm
Temperature Range: RT-340°C
Permissible Ambient Temperature: 5-40°C
Temperature Increment: 1°C
Control Accuracy of Work Plate: ±1(<100°C), ±1%(>100°C)
Temperature Accuracy: ±0.1°C
Safety Temperature: 360°C
Control Accuracy with Sensor PT1000: ±0.2°C
Permissible Relative Humidity: 0.8
Heating Warning: 50°C
Motor rating Input [W]: 18
Motor rating output [W]: 10
Heating Output: 500 W
Work Plate Size: 135 mm
Stirrer Dimension: 80 mm
Platform Material: Stainless steel with ceramic coating
Speed Display: LCD
Speed Display Resolution: ±1 rpm
Temperature Display: LCD
Remote Control (RS232 interface): Yes
Motor Type: Brushless DC motor
Protection Class: IP42
Overall Dimension: 160Wx280Dx85H mm
Weight: 2.8 kg
Power: 550 W
Power Supply: 100-120 V/200-240 V, 50/60 Hz
Optional Accessories:
SX1002Stirrer bar 10mm x 6mm
SX1003Stirrer bar 15mm x 8mm
SX1004Stirrer bar 20mm x 8mm
SX1005Stirrer bar 25mm x 8mm
SX1006Stirrer bar 30mm x 6mm
SX1007Stirrer bar 40mm x 8mm
SX1008Stirrer bar 50mm x 8mm
SX1009Stirrer bar remover - Length of 200mm
SX1012Temperature sensor - Length of 230mm
SX1013Temperature sensor with glass coating; Length of 230mm
SX1014Temperature sensor - Length of 100mm
SX1015Reaction block; For 50ml round bottom flask (one flask capacity)
SX1016Reaction block; For 100ml round bottom flask (one flask capacity)
SX1017Reaction block; For 250ml round bottom flask (one flask capacity)
SX1018Reaction block; For 500ml round bottom flask (one flask capacity)
SX1019Blue carrying plate; Used with SX1021 to SX1026
SX1020Blue Fixed ring; Used with SX1021 to SX1026
SX1021Red quarter pie; 11 holes, 4 ml reaction vessel, Ø15.2mm, 20mm depth, used with SX1019 and SX1020
SX1022Purple quarter pie; 4 holes, 20 ml reaction vessel, Ø28mm, 24mm depth, used with SX1019 and SX1020
SX1023Blue quarter pie; 4 holes, 30 ml reaction vessel, Ø28mm, 30mm depth, used with SX1019 and SX1020
SX1024Black quarter pie; 4 holes, 40 ml reaction vessel, Ø28mm, 43mm depth, used with SX1019 and SX1020
SX1025Green quarter pie; 6 holes, 8ml reaction vessel, Ø17.8mm, 26mm depth, used with SX1019 and SX1020
SX1026Golden quarter pie; 4 holes, 16ml reaction vessel, Ø21.6mm, 31.7mm depth, used with SX1019 and SX1020
SX1027Stirrer bar; Stirrer bar (65mm x 8mm), 1pc/pk
SX1028Stirrer bar; Stirrer bar (80mm x 13mm), 1pc/pk
SX1029Protective cover; For hotplate model
