LABTT THB-62.5MDX Auto Turret Digital Brinell Hardness Tester

Brinell scale: HBW1/1、HBW1/2.5、HBW1/5、HBW2.5/6.25、HBW1/10、 HBW2.5/15.625、 HBW5/25、HBW1/30、HBW2.5/31.25、 HBW2.5/62.5、 HBW5/62.5

Test force（Kgf）: 1Kgf(9.8N)、2.5Kgf(24.5N)、5Kgf(49N)、6.25Kgf(61.29N)、10Kgf(98N)、15.625Kgf(153.23N)、25Kgf(245.2N)、30Kgf(294N)、31.25Kgf(306.47N) 、62.5Kgf(612.94N)、

Carried standard: BSEN 6506, ISO 6506, ASTM E10, GB/T231

Min measuring unit: 0.1um

Hardness resolution: 0.1HBW

Test microscope magnification: 50X、100X

Duration time: 0～99S

Data output: LCD display

Data storage: data is saved in USB disk as EXCEL format

Max Height of Specimen: 180mm

Distance of Indenter to outer wall: 160mm

Size: 590×200×680mm

Weight: 50kg

Power: AC220+5%,50～60Hz
