Test force: 10gf (0.098N)、25gf (0.245N)、50gf (0.49N)、100gf (0.98N)、 200gf (1.96N)、300gf (2.94N)、500gf(4.9N)、1Kgf (9.8N)
Carried standard: GB/T4340.2、ASTM E92
Measurement resolution: 0.01µm
Data output: 8-inch touch screen displays readings, can store 20 kinds of test results, built-in printer and rs-232 interface, optional U disk
Conversion: Rockwell、Brinell
Hardness measurement range: 8~2900HV
Test force loading mode: Automatic （loading、dwell、unloading）
Magnification of microscope: 400X(testing)，100X（testing、observation）
Dwell time: 1-99s
Max. Height of specimen: 100mm
Distance from the center to the outer wall of the indenter: 130mm
X-Y stage: dimension：100*100mm movement ：25*25mm
Size: 540*260*650mm
Weight: 约50Kg
Power: AC220V+5%，50-60Hz
Standard Accessory:
Axle weight: 1
10X eyepiece: 1
XY stage: 1
level: 1
Power cable: 1
Certificate, warranty card: 1
Weight: 6
Micro standard block（high、medium）: Each 1
Regulating screw: 4
Fuse （2A）: 2
Dust bag: 1
Manual: 1
