Gain: 3.2 dBi, 2.6 dBi, 3.4 dBi, 4.2 dBi, 4 dBi, 4.4 dBi, 4.2 dBi, 4.3 dBi, 5.4 dBi, 2.4 dBi, 3 dBi
VSWR: 1.2:1, 1.2:1, 1.2:1, 1.6:1, 1.3:1, 1.3:1, 1.3:1, 1.2:1, 1.2:1, 1.6:1, 1.7:1
Style: Panel
Length: 7.6 mm
Diameter: 180 mm
Impedance: 50 Ohms
Cable Type: 30 cm Coax
Application: In-Building Systems, FirstNet/Public Safety, Small Cells, Meeting Rooms, Offices, Hotels, Museums, IDAS, Librairies, Retails Malls, Bus Terminals and Train Stations
Unit Weight: 230 g
Cable Length: 30 cm
Polarization: Linear, Horizontal
Power Rating: 50 W
Mounting Style: Ceiling Mount
Number of Bands: 11 Band
Center Frequency: 752 MHz, 859 MHz, 885 MHz, 1450 MHz, 1785 Mhz, 1920 Mhz, 2045 MHz, 2400 MHz, 2600 MHz, 3550 MHz, 3900 MHz
Mechanical Style: Module
Maximum Frequency: 4 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: N Female
Protocol - WiFi - 802.11: WiFi, WiMAX
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 30 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), GSM, DCS, UMTS, AWS-3
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
