Gain: 3.1 dBi, 3.1 dBi, 2.8 dBi, 5.9 dBi, 4.5 dBi, 4.3 dBi, 5.9 dBi, 6.9 dBi
VSWR: 1.7:1, 1.7:1, 1.7:1, 1.8:1, 1.7:1, 1.7:1, 1.5:1, 1.5:1
Style: Panel
Length: 218.7 mm
Diameter: 43.5 mm
Impedance: 50 Ohms
Cable Type: 46 mm Coax
Application: In-Building Systems
Unit Weight: 410 g
Power Rating: 50 W
Mounting Style: Ceiling Mount
Number of Bands: 8 Band
Center Frequency: 752 MHz, 859 MHz, 920 MHz, 1795 MHz, 1920 MHz, 2040 MHz, 2400 MHz, 2600 MHz
Mechanical Style: Module
Maximum Frequency: 2.7 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: N Female
Protocol - WiFi - 802.11: WiFi, WiMAX
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 30 C
Protocol - Cellular, NBIoT, LTE: 3G/4G, Cellular (NBIoT, LTE)
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
