Envelope Size: 5.0 x 4.9 x 1.7 in. (127 x 124 x 43 mm)
Weight: 35 oz. (1 kg)
Acceleration Ranges: 5, 10, 20, 50, 100 and 200g (full scale)
Accelerometer Type: Triaxial piezoelectric (internal), six external channels (optional)
Sampling Rates: 50, 100, 200, 250, 500, 1000, 2500, 5000, and 10,000 samples per second
A/D Conversion: 16-bit
Anti-Alias Filter: 4-pole, low-pass Butterworth filter, 10, 20, 25, 50, 100, 200, 250 and 500 Hz. (cut-off frequency)
3-dB Frequency Response: 0.4 Hz. to filter setting
GPS Run Time: 100 hours of vehicle movement (lithium batteries), 50 hours of vehicle movement (alkaline batteries), GPS turns off when instrument is not moving
Temperature Measurement Range: -40° to 60°C (-40° to 140°F)
Humidity Measurement Range: 5% to 95% RH, non-condensing
Atmospheric Pressure Measurement Range: 10 to 1100 mbar
